Features:
-P25 Phase 1 Conventional, Trunking*1and Phase 2 Trunking*1Capable
-DHS P25 CAP Certified (TIA-102) Compliant for Multiple Vendor Interoperability
-Optional FIPS Compliant AES Encryption Unit*1
-P25 Voting Scan*1 (P25 Conventional Mode)
-Up to 1024 Channel Capacity with 128 Zones
-IP68 Waterproof Protection (1 m depth/1 hour)
-High Visibility and Readability with a Color LCD
-Icom’s custom high power handling capacity speaker for 1300 mW of powerful audio
-Built-in Bluetooth®*2, Voice Recording and P25 Packet Data (GPS)*1Functions
-Enhanced Dual-Rate AMBE+2™ Vocoder
* License key upgrade required
**Version without Bluetooth also available. Ask your Dealer for details.
General Specifications
| IC-F7040T/S | ||
|---|---|---|
| Frequency coverage (* Depends on the transceiver version) |
USA | 769–775 MHz (for RX/TX); 799–805 MHz (for TX only), 851–869 MHz (for RX/TX); 806–824 MHz (for TX only) |
| EXP | 764–776 MHz (for RX/TX); 794–806 MHz (for TX only), 851–870 MHz (for RX/TX); 806–825 MHz (for TX only) |
|
| Number of channels | 1024 channels /128 zones | |
| Type of emission (* Depends on the transceiver version) |
16K0F3E, 14K0F3E, 11K0F3E, 8K50F3E, 8K10F1E/F1D, 8K10F1W |
|
| Power supply requirement | 7.5 V DC nominal | |
| Current drain (approximate) | Tx | 1.6 A |
| Rx | 620 mA (Max. audio w/Internal SP) 250 mA (Standby) |
|
| Antenna impedance | 50 Ω | |
| Operating temperature range | −30 °C to +60 °C; −22 °F to +140 °F (Radio specifications) |
|
| Dimensions (W × H × D, Projections not included) |
53.6 × 123.5 × 38.2 mm; 2.1 × 4.9 × 1.5 in (With BP-284) | |
| Weight (approximate) | 345 g, 12.2 oz (with BP-284, MB-133, FA-S100U) | |
